19
IMPORTANT: Figures shown are for non-reversing models ONLY.
IMPORTANT: The wire size must be properly sized to handle the related current.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Gas
Electric
AD-20
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
NOTES: A.
B.
C.
When fuses are used they must be dual element, time delay, current limiting, class
RK1 or RK5 ONLY. Calculate/determine correct fuse value, by applying either
local and/or National Electrical Codes to listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) motor curve type ONLY. For
others, calculate/verify correct breaker size according to appliance amp draw
rating and type of breaker used.
Circuit breakers for 3-phase (3Ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
120 1ш 2 10.9 --- 15
240 1ш 3 6 15
240 1ш 3 5.8 --- 15
240 1ш 3 --- 28.5 35
240 1ш 3 28.3 --- 35
416 3ш 4 --- 18 25
