6
SECTION II
SPECIFICATIONS
A. SPECIFICATIONS
* Contact factory for information not listed, 3-phase (3ø) figures shown are for 4-wire service, non-reversing.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Gas
Electric
MAXIMUM CAPACITY (DRY WEIGHT) 20 lbs 9 kg
BASKET (TUMBLER) DIAMETER 25.75” 65.4 cm
BASKET (TUMBLER) DEPTH 24” 60.95 cm
BASKET (TUMBLER) MOTOR 1/4 HP 0.19 kw
BLOWER MOTOR 1/8 HP 0.1 kw
BASKET (TUMBLER) VOLUME 7.5 cu.ft. 0.21 cu.m.
VENT CONNECTION 4” 10.2 cm
CABINET WIDTH 27” 68.6 cm
CABINET DEPTH 30” 76.2 cm
CABINET HEIGHT 41” 104 cm
VOLTAGE AVAILABLE
120v /60 Hz/1ø, 240v/60 Hz/1ø,
240v/50 Hz/1ø
HEAT INPUT 40,000 btu/hr 10,080 kcal/hr
AIRFLOW 240 cfm 6.79 cmm
INLET PIPE CONNECTION 3/8” N.P.T.
OVEN SIZE
1ш
3ш
5.4 kw
8.1 kw
VOLTAGE AVAILABLE
240v/60 Hz/1ø, 240v/50 Hz/1ø,
416v/50 Hz/3ø
Shaded areas are stated in metric equivalents
