RUGGED YET REFINED
Designed for industrial, commercial and institutional use, Yale’s 5400LN
Series heavy-duty cylindrical lockset offers no compromise when it comes
to rugged reliability and performance. With key construction features,
such as our patented Free Wheeling lever mechanism, wear-resistant
chassis plates, heavy-duty lever return springs and through-bolting, this
Grade 1 trendsetter proves time and again why it’s the favorite among
architects and building owners who demand the highest standard of
product quality.
And who says a lockset can’t be tough and look good at the same time?
The 5400LN features three aesthetic lever designs and a diverse line of
eleven architectural finishes, including three PVD lifetime finishes, which
allow the freedom of enhancing any décor. With a lifetime warranty
against lever sag and lever spring breakage, you’ll never have to worry
about your intended attraction becoming an unintended distraction.
Page 2
Introduction . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . .3
Lever Designs . . . . . . . . . . . . 4
Lockset Functions . . . . . . . 5-7
Cylinders . . . . . . . . . . . . . . 8-9
Electrified . . . . . . . . . . . . . . .10
Latchbolts . . . . . . . . . . . . . . 11
Strikes . . . . . . . . . . . . . . . . .12
Suggested Specification . . . . 13
Ordering Information . . . . . 14
CONTENTS
5400LN Series Cylindrical Lock
FINISHES
ANSI
Code
Finish
605* Bright Brass, PVD
606* Satin Brass, PVD
609
Satin Brass, Blackened, Satin
Relieved, Clear Coated
612 Satin Bronze, Clear Coated
613
Satin Bronze, Oxidized and
Oil Rubbed
613e*
Satin Bronze, Oxidized and
Oil Rubbed, PVD
616
Satin Bronze, Blackened, Satin
Relieved, Clear Coated
619
Satin Nickel Plated, Clear
Coated
625 Bright Chrome Plated
626 Satin Chrome Plated
693 Black Powder Coat
FREE WHEELING LEVER TRIM
All 5400LN locking functions
feature the patented (Patent No.
4920773) Free Wheeling lever
mechanism. When the outside
lever is locked, it will rotate freely
up and down while remaining
securely locked.
A.D.A.
The 5400LN meets accessibility
guidelines of the Americans with
Disabilities Act and the
requirements of the Uniform
Federal Accessibility Standards and
ANSI 117.1, all requiring ease of
accessibility for the handicapped.
INSTALLATION
Fits ANSI Spec. 115.2, which
covers Hollow Metal Doors and
Frame Preparation for Cylindrical
Locksets, and doors with ANSI
Spec A115.18 “Spider Cut Out.”
WARRANTY
The 5400LN Key-in-Lever
cylindrical lock carries a
comprehensive five-year warranty.
Likewise, the lockset carries a
lifetime warranty against lever sag
and lever spring breakage. Ask
your Yale sales representative for
complete warranty information.
ISO 9001
Designed and
manufactured in
a certified ISO 9001
facility.
*PVD finish standard on 605 and 606.
Available as an option on 613 (as 613e)
for customers desiring a non-wearing
finish.
PVD LIFETIME FINISH
Physical Vapor Deposition (PVD)
is a technologically advanced finish
coating that provides the ultimate
surface protection against
environmental elements and
everyday wear and tear. PVD
matches clear coated finishes in
appearance, yet surpasses them in
durability. Yale warrants all its
PVD finishes against corrosion,
tarnish, wear, discoloring and
peeling for the lifetime of the part
to which it has been applied. Ask
your sales representative for
specific warranty information.
