Product Information
2
AV2SM A/V Switcher
Specifications (Cont.)
Rear Panel:
INPUT A VIDEO
BNC female connector
INPUT A AUDIO
6-pin cable jack, audio and control input
INPUT B VIDEO
BNC female connector
INPUT B AUDIO
4-pin cable jack
Captive-wire screw terminals Allows stereo (unbalanced) line-level audio
Switching Modes:
Automatic
AV2SM switches to the A source; if no input is detected the AV2SM automat-
ically switches to the B source. If both A and B sources are present, the
default is the A source.
Manual
AV2SM determines which source to use based on the state of the SELECT
pin on the rear panel.
Enclosure
Molded black matte plastic
Included Accessories
• Two 4-pin cable connectors
• One 6-pin cable connector
• One 2-pin power connector
Optional Accessories
AC-RK Accessory Rack Kit
