2
User Guide
Front view of the computer
Attention: Be careful not to block any air vents on the computer. Blocked
air vents can cause overheating.
1 2
3 7 6 5 4 8 9 10 12 11
13
Built-in microphone Built-in camera
Hard disk drive indicator Bluetooth status indicator
Wi-Fi status indicator Volume down
Volume up Brightness down
Brightness up Novo Vision switch
PC mode/HDMI-in switch Monitor ON/OFF
Built-in IR receiver (Only functional on
models equipped with a IR receiver
module)
Attention: The effective range of the Built-in IR Emitter is 10 feet.
