Appendix A. Replacing components
33
6 Align the notch on the contact edge of the new memory module with the
protrusion of the socket and gently insert the memory module into the
socket at a 30-45° angle. Then pivot the memory module down until it
snaps into place. Ensure that the memory module is firmly installed and
cannot be moved easily.
7 Reinstall the compartment cover, and then reinstall the screws to secure
the cover.
8 Reinstall the battery pack.
9 Turn the computer over again. Connect the AC power adapter and all
cables.
To make sure that the memory module is installed correctly, do the
following:
1 Turn off the computer.
2 Press the Novo button and then select BIOS Setup. The System Memory
item shows the total amount of memory installed in your computer.
Attention:
• Do not touch the contact edge of the memory module to avoid any damage.
1
2
2
