Alps Electric miniSD SCHF Series - Manual (Page 2)

30
For
SD Memory
Card
For
miniSD™
Card
For
microSD™
Card
For
W-SIM
For
Memory
Stick Micro™
Combine Type
For
Express
Card™
For
Compact
Flash™
For PC cards
supporting
CardBus
For CMOS
Camera Module
For
Memory
Stick™
DAT2
CD/
CMD
CLK
9 1 2 3 1011 4 5 6 7 8
5.2
min.
1.6 0.3
0.7
1
18.5
11.12
0.6
8.85
20
0.9
1.4
21.5
5.5
7.7
1.2
2.54
VDD VSS2 DAT1
DAT0 VSS1
DAT3
Style
Unit:mm Dimensions
Cautions
1. This product has been designed and manufactured for use in ordinary electronic equipment, such as AV equipment,
electric home appliances, office machines and communication equipment. In case of using the products for highly
sensitive applications such as medical, aviation, aerospace and security, the set makers shall require to include
measures necessary to meet product safety requirements of such specific applications. Such measure may include
additional protection circuits and redundant circuits, for example.
2. To prevent contact failures caused by sulfuration or oxidation on the contact and terminal or deterioration of
solderability caused by film forming, please follow the instructions given below.
1 Do not store the product in locations with high temperature or high humidity. Keep it in an atmosphere free from
corrosive gases including sulphurous or chlorinate gas. Do not stack.
3 To store the product after opening the package, keep it in a sealed polyethylene bag. Store in a dark, cool place,
out of direct sunlight. Use the product as soon as possible.
Note
Inside miniSD™ Adapter: Vss1 must be connected Vss2
miniSD™ Card Adapter for microSD™ card SCHF Series
Logo text is used for reference.
Product Surface Logo
