Alps Electric miniSD SCHF Series User Manual
Minisd, Card adapter for microsd™ card, Schf
29
For
SD Memory
Card
For
miniSD™
Card
For
microSD™
Card
For
W-SIM
For
Memory
Stick™
For
Memory
Stick Micro™
Combine Type
For
Express
Card™
For
Compact
Flash™
For PC cards
supporting
CardBus
For CMOS
Camera Module
SCHF1A0100
miniSD
TM
Card Adapter for microSD™ card
SCHF
Series
Resin body offers high reliability along with twist-resistant robust structure.
General SD card hosts can be used by inserting miniSD™
card into the adaptor.
Unique half-lock structure stops media from flying out
during ejection.
Features
For digital still cameras, digital camcorders, mobile phones,
PCs and personal digital assistants
Applications
microSD™ Card
Manual insertion/removal
500V AC 1minute
Applicable media
Structure
Items
Specifications
Media ejection
structure
Mounting type
Mounting style
25
to
85
1,000M
min.
100m
max.
10,000cycles
Operating
temperature range
Performance
Contact resistance
Initial
Insertion and
removal cycle
Voltage proof
Insulation resistance
Initial
Typical Specifications
Media ejection structure
Manual insertion/removal
Packing system
Tray
Product No.
Product Line
NEW
