SPECIFICATIONS
Standard
IEEE 802.11b/g Standard
Host Interface PCI Specification Rev:2.2 and 2.3
Operating Voltage
3.3V ± 5%
Power Requirement
Power consumption at 11g
TX: TBD
RX: TBD
RF Connector Type
3 Reverse SMA
Frequency Range
2.412GHz-2.4835GHz
Number of Selectable Channels
USA, Canada (FCC): 11 channels (2.412GHz~2.462GHz)
Europe (CE): 13 channels (2.412GHz~2.472GHz)
Japan (TELEC): 14 channels (2.412GHz~2.4835GHz)
Modulation Technique
802.11b: Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
802.11g: Orthogonal Frequency Division Multiplexing(OFDM)
Data Rate
802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)
802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6
Mbps)
802.11b: Both Short and Long preamble
Preamble
802.11g: Long preamble only
Modulation
11g: Orthogonal Frequency Division Multiplexing (OFDM)
54Mbps/48Mbps:QAM-64
36Mbps/24Mbps:QAM-16
18Mbps/12Mbps:QPSK
9Mbps/6Mbps:BPSK
11b: Direct Sequence Spread Spectrum (DSSS)
11Mbps/5.5Mbps:CCk
2Mbps:DQPSK
1Mbps:DBPSK
Security
Hardware-Based Encryption/Decryption Using WEP 64/128, WPA, WPA2,
802.1x and 802.11i
Output Power
54Mbps OFDM: 18.5 ±0.5 dBm
11Mbps CCK: 19 ±1 dBm
Receiver Sensitivity
-79dBm at 54Mpbs, 10% PER
<-90dBm at 11Mpbs, 8% PER
Physical Specifications
Weight: 50g
Dimension: 120(L) x 72(W) mm
Environment Specifications
Operating Temperature: 0~60°C ambient temperature
Storage Temperature: -20~70°C ambient temperature
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
EMC Certification FCC Part 15.247 in US. EN300328 and EN300826(en301489-17) in Europe
