Before You Begin
Note: The distance and times provided in this
instruction guide are approximate measurements.
Charge the Battery
It takes 1.5 hours to fully charge the battery. The
charge lasts 10 hours with typical use during active
tracking or 16 days on standby.
1. Connect the charging cable into the USB port
( e4) from one of the following power sources:
AC outlet, personal computer USB port,
(see “Power Source Specifications” on page 12).
2. The LCD backlight turns on, the battery strength indicator (d2)
appears on the LCD and the green LED indicator (e1) blinks.
After 5 seconds the backlight turns off.
3. When charged, the battery strength indicator (d2) is full, and
the green LED indicator (e1) light is steady.
4. Disconnect the charging cable from the USB
port (e4). The features cannot be accessed while connected to
the charging cable.
The unit displays the battery charge level in all modes, except
when the latitude/longitude/satellite information is displayed. It
is recommended to recharge when the bars across the battery
strength indicator (d2) are at 25% or less.
Power On to Ready Mode
1. Press and hold return (e3) for 2–3
seconds. The LCD backlight turns on and the
start-up screen appears.
2. The unit immediately starts acquiring GPS data,
indicated by the blinking green LED indicator (e1),
and the LCD displaying a blinking satellite icon and the message
Searching.
3. When your current position is determined, the green LED
indicator (e1) is steady, the LCD satellite icon disappears
and a sequence of messages appears:
Initializing > Ready.
