Rear view of the chassis – Lenovo Erazer X700 Desktop User Manual
Page 8
3
User Guide
Rear view of the chassis
(If the rear view configuration shown in this chapter is different from the rear of your
computer, please refer to the rear of your computer.)
Power connector
PCI Express X 16 graphics adapter slots (some models are equipped with a
graphics card)
PCI Express X 1 adapter slots (some models are equipped with a WIFI card
or TV tuner card)
Audio connectors
Ethernet connector
USB 3.0 connectors
USB 2.0 connectors
Optical S/P DIF connector
Coaxial S/P DIF connector
USB 3.0 standard B connector
Power supply for portable HDD (Output: 12Vdc, Max 3A)
