Front view of the chassis
Attention: Be careful not to block any air vents on the computer. Blocked
air vents can cause overheating.
Microphone connector
Headphone connector
USB 3.0 connector
USB 2.0 connector
Overclock switch button
Power button / Engine Srart button
Memory card readers
Optical drives
Hot-swappable hard disk frame
Expansion hard disk frame slots bays
