46

Lenovo IdeaPad U300e Hardware Maintenance Manual

Figure 8. Removal steps of the speakers and microphone (continued)
Remove the microphone in the direction shown by arrow

3

.

3

When installing: Make sure that the microphone connector is attached firmly.
