Hardware Maintenance Manual
30
4. Refer to the “Completing the installation”.
Replacing a memory module
Attention
Do not remove the computer cover or attempt any repair before
reading the “Important safety information” in the Safety and Warranty
Guide that was included with your computer or in the Hardware
Maintenance Manual (HMM) for the computer. To obtain copies of
the Safety and Warranty Guide or HMM, go to the Support Web site at
http://consumersupport.lenovo.com.
To replace a memory module:
1. Open the computer cover. Refer to “Opening the computer cover”.
Note: For this procedure, it helps to lay the computer on its side.
2. Pivot the drive bay assembly upward to gain access to the system
board.
3. Locate the memory module connectors. Refer to “Locating
components”.
4. Remove the memory module being replaced by opening the retaining
clips as shown.
5. Position the new memory module over the memory connector. Make
sure the notch on the memory aligns correctly with the connector
key on the system board. Push the memory module straight down
into the connector until the retaining clips close.
