53
Lenovo Yoga 2 Pro (13″)
Figure 12. Removal steps of MIC board, LCD cover, and hinges (continued)
Adjust the hinges in the direction shown by arrows
4
. Then remove the hinge
rubbers
5
and pull out the cables.
4
4
5
Remove the screws 6 and then remove the LCD module in the direction
shown by arrow
7
.
6
6
6
7
Step Screw (quantity) Color Torque
6
M2 × 3 mm, flat-head, nylok-coated (3)
LCD module to LCD cover
Black 1.85+/-0.15 kgf*cm
