Hardware Maintenance Manual
42
Replacing the LCD panel
To replace the LCD panel
1. Remove the computer cover. Refer to ”Removing the computer cover“.
2. Remove all the components on the top of the LCD panel bracket.
3. Remove the 10 screws that secure the LCD panel bracket to the chassis.
4. Remove the LCD panel bracket.
1 1
2
5. Remove the four screws that secure the LCD panel to the bracket.
6. Remove the LCD panel.
7. Screw back the new LCD panel into the bracket.
8. Screw back the LCD panel bracket into the chassis.
9. Install all related components back to the LCD panel bracket.
10. Install the computer cover. Refer to “Completing the installation”.
