Chapter 1. Getting to know your computer
5
Bottom view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Battery latch -
manual The manual battery latch is used to keep the battery pack
secured in place.
Hard disk drive
(HDD)/Mini PCI
Express Card slot
compartment
SIM card slot
Insert a SIM card (not supplied) for using Mobile
Broadband.
Notes:
• In order to be able to insert a SIM card into this slot, you must first disconnect the AC
adapter and remove the battery pack.
• For details, see “Using Mobile Broadband” on page 23.
Speakers The stereo speakers provide rich and powerful sound.
Battery pack For details, see “Using AC adapter and battery” on page 8.
Battery latch -
spring loaded The spring-loaded battery latch keeps the battery pack
secured in place.
Memory
compartment Houses the computer's memory modules.
a
b
c
f
d
e
g
a
b
c
d
e
f
g
