CHAPTER 7. (CONNECTION)
Connecting to a wide TV/ an AV TV
Before connecting
Turn off the power of this unit and the equipment to be connected.
Refer to the instructions for the equipment to be connected.
To VIDEO OUT jack
To AUDIO OUT jack
Video connecting cable(supplied)
Audio connecting cable(supplied)
To video input jack To Audio input jacks
To connect to a TV set equipped with S-video (optional) input
Use the S-video connecting cable instead of the video connecting cable to connect the
S-VIDEO jack of this unit and the S-VIDEO input jack of the TV set.
To set the color system of the connected TV
Use the setup menu to change the TV (PAL/NTSC) color system, refer to Preference Page.
S-video connecting cable (optional)
