54
IdeaPad S205s Hardware Maintenance Manual
1130 Bluetooth card
For access, remove these FRUs in order:
• “1010 Battery pack” on page 34
• “1020 Dummy card” on page 35
• “1040 Keyboard” on page 37
• “1050 Base cover” on page 39
• “1060 PCI Express Mini Card for wireless LAN” on page 42
• “1070 LCD unit” on page 44
• “1080 Hard disk drive (HDD)” on page 46
• “1090 DIMM” on page 47
• “1100 Fan assembly and heat sink assembly” on page 48
• “1110 System board” on page 50
Figure 13. Removal steps of bluetooth card
Remove the bluetooth card in the direction shown by arrow
1
.
1
