Lenovo Horizon 2e Table PC User Manual
Page 27
Chapter 7. Locating connectors, controls and components
This section provides illustrations to help locate the various connectors, controls and components of the
computer.
Front view
The following illustration shows the location of controls and components on the front of the computer.
Attention: Be careful not to block any air vents on the computer. Blocked air vents can cause overheating.
1
2
3
4
5
1
6
1. Built-in microphone
4. Ambient light sensor
2. Camera LED indicator
5. Windows button
3. Built-in camera
6. Near Field Communication (NFC) (selected models
only)
