Page 68
64
IdeaPad S10-3s Hardware Maintenance Manual
Table 5. Parts list—Overall
No. FRU
FRU no.
1
LCD unit (see “LCD FRUs” on page 67.)
2
Keyboard (see “Keyboard” on page 69.)
3
LM30 TOUCHPAD W/COVER HAIBO
31043691
4
LM30 Upper CASE WHITE IMF HAIBO
31043692
4
LM30 Upper CASE WHITE IMF WIND
31043699
5
CPU, Intel Pineview N450 1.66G A-0 BGA processor
102000754
5
CPU, Intel Pineview N470 1.83G A-0 BGA processor
102000753
6
LM30 MB N450 1.66G W/OD DA 09298-1
11012086
6
LM30 MB N470 1.83G W/OD DA 09298-1
11012087
7
LM30 IO BD 09714-1 SVT (D)
11012089
8
WLAN card, 802.11a/b/g/n, Intel 6200N MOW M PCIE NB HMC 20002324
8
WLAN card, 802.11b/g/n, Intel 1000N MOW M PCIE NB HMC 20002329
8
WLAN card, 802.11b/g/n, Gtc BCM4313 M 802.11N MOW NB 20002362
8
WLAN card, 802.11b/g/n, Cbt AR9285 HB95 BGN Wistron NB 20002343
8
WLAN card, 802.11b/g/n, Liteon AR9285 HB95 BGN Wistron NB 20002353
8
WLAN & BT, 802.11b/g && BT2.1, Azurewavet BCM4312HMGB
SAR Wistron
20002355
8
WWAN card, WCDMA/HSDPA 7.2M, Ericsson F3607gw
WCDMA 850MHz WWAN
11011296
8
WWAN card, WCDMA/HSDPA 7.2M, Ericsson F3607gw
WCDMA 900MHz WWAN
11011295
8
WWAN card, WCDMA/HSDPA 7.2M, Huawei EM770U
WCDMA MOW WWAN card
11011654
8
WWAN card, WCDMA/HSDPA 7.2M, Huawei EM770W
WCDMA MOW WWAN card
11011653
8
WWAN card, WCDMA/HSDPA 7.2M, Huawei EM770
HSDPA MiniPCIE WWAN card
11010888
8
WWAN card, EVDO, Huawei EM660 EV-DO MiniPCIE
WWAN card
11010853
8
WWAN card, EVDO, ZTE MC2716 EVDO MiniPCIE WWAN
card
11011055
8
WWAN card, Gobi, Qualcomm GOBI WCDMA/EVDO
WWAN Card
11011655
8
WWAN card, TD-SCDMA, TC LC5730D TD-SCDMA
MiniPCIE WWAN card
11011652
8
WWAN card, TD-SCDMA, TC LC5730C TD+CMMB
MiniPCIE WWAN card
11011598
8
WWAN card, TD-SCDMA, ZTE MU302 TD-SCDMA
MiniPCIE WWAN card
11011600
8
WWAN card, TD-SCDMA, ZTE MU303 TD+CMMB MiniPCIE
WWAN card
11011599
8
GPS, AzureWave BCM4750 GPS USB module
20002341
