6
Hardware Replacement Guide
Camera LCD On/Off indicator
Built-in microphone Hard disk drive indicator
LCD On/Off Wireless LAN card indicator
Brightness down Bluetooth indicator
Brightness up Power button
Left and right view
The following illustrations show the location of connectors on the left and right side
of the computer.
Attention: Be sure not to block any air vents on the computer. Blocked air
vents may cause thermal problems.
2
3
4
1
2
5
Memory card reader Microphone connector
USB connector Optical drive
Headphone connector
31045699 IdeaCentre B3 HRG V1.1 (EN)(R).indd 6 2010-7-23 17:02:42
