Power status LED Color Description
On Green The server is on.
Off None The server is off.
Blinking Green The server is in ACPI S1 mode, which also is known
as Power On Suspend (POS) mode. In this mode,
the microprocessor(s) are not working while other
hardware devices are still working.
2 ID button with ID LED
When you press the ID button on the front panel, the ID LEDs on both the front and rear of the server are
lit to help you locate the server among other servers. You also can turn on the ID LEDs using a remote
management program for server presence detection.
ID LED Color Description
On Blue The server is identified.
Off None The ID LED is not in use or the server is not identified.
3 NIC 1 status LED
4 NIC 2 status LED
The NIC 1 status LED indicates the LAN status for the Ethernet connector 1 on the rear of the server.
The NIC 2 status LED indicates the LAN status for the Ethernet connector 2 on the rear of the server.
NIC status LED Color Description
On Green The server is connected to a LAN.
Off None The server is disconnected from a LAN.
Blinking Green The LAN is connected and active.
