Front view – Lenovo 3000 H305 Desktop User Manual
Page 27
Chapter 7. Locations
25
Computer cover
Power supply
Motherboard
Chassis
Optical disk drive bay
Optical disk drive
Vent
Heatsink
Fan
Hard disk drive
Hard disk drive bay
Front bezel
Card reader (Selected models)
Audio & USB connectors
Front view
The following illustrations show the location of connectors on the front of
the computer.
3
1
2
4
5
6
