Rear view – Lenovo IdeaCentre K320 User Manual
Page 9
Hardware Replacement Guide
Optical drive (Some models are equipped with only one optical drive.)
Power Dial switch
Rear view
The following illustration shows the location of connectors on the rear of the computer.
Voltage selection switch (selected models only)
Power connector
PS/2 keyboard connector
PS/2 mouse connector
On-board VGA connector ( selected models only)
HDMI port
USB connectors (6)
Ethernet connector
SPDIF port
Audio line-out sockets (2)
Audio line-in sockets (2)
31041595_K3_HRG(H57)_EN_V3.0.ind6 6
2009.11.17 10:53:28 AM
