Hardware Replacement Guide
Note 1: Replacement of some models equipped with
graphic adapter bracket is different.
Please remove the plastic bracket first as the following:
1. Remove the two screws that secure the plastic bracket at the bottom of the
chassis.
2. Lift the plastic bracket out of the chassis.
3. Then remove the adapter as above.
After the Graphic Adapter is installed , install the bracket as the
following:
1. Install the plastic bracket into the chassis so that the screw holes in the plastic
bracket align with those in the chassis. Let the slot on the plastic bracket clip
the adapter.
