Abocom PLS485 User Manual
Page 2
2/2
Product outlook
Specification
Main Chipset
Intellon INT5500 + INT1200 + Marvell 88E6060
Standard support
HomePlug 1.0 Turbo (85Mbps) & HomePlug 1.0 (14Mbps)
Interface
One Powerline port, four 10/100M Ethernet ports
Power
AC 100-240V, 50-60Hz, 0.1A
Dimension (W x D x L)
121.4 mm x 100 mm x 28.5 mm.
LED PWR:
Yellow-Green
On: Power on
Off: Power off
PLC: Yellow-Green
On: Powerline in link.
Blink: Powerline in activity
Off: Powerline in no-link.
LAN (1-4): Yellow-Green
On: Ethernet port in link.
Blink: Ethernet port in activity
Off: Ethernet port in no-link.
Operating Operating
Temperature:
0~40ºC
(32~104ºF)
Relative Humidity:
10%~90% non-condensing
Storage Temperature:
-10~70ºC
(14~158ºF)
Relevant Humidity: 5%~95% non-condensing
C
ERTIFICATIONS
FCC Part 15B & 15C, Class B; CE Class B (EN55022/EN55024);
UL 60950-1, CB.
