background image

Troubleshooting

www.kodak.com/go/support

43

Computer/connectivity problems

Direct printing (PICTBRIDGE enabled printer) problems

You cannot take a

Turn the camera off, then on again.

Depress the Shutter button all the way (

see page 6

).

Insert a new/charged battery (

see page 1

). Charge the Li-Ion

battery whenever necessary.

Memory is full. Transfer pictures to the computer (

see page 37

),

delete pictures (

see page 22

), or insert another card.

Memory card not
recognized or camera
freezes with card

Card may be corrupted. Format the card in the camera (

see

page 36

).

Use another memory card. Only SD or SDHC Cards are supported.

Cannot find the
desired picture/video

To view pictures on a card or in internal memory,

see page 21

.

Status

Solution

Slide Show does not
run on an external
video device

Adjust the camera Video Out setting to NTSC or PAL (

see

page 35

).

Make sure the external device settings are correct. (See the
device’s user guide.)

Computer does not
communicate with
the camera

Turn off the camera, then turn it back on.

Make sure the battery is charged and installed correctly (

see

page 1

).

Make sure the KODAK Camera USB Cable, Micro B / 5-Pin is
connected to the camera and the computer (

see page 37

). Then

turn on the camera.

See KODAK Software Help at

www.kodak.com/go/camerasw

.

Status

Solution

Cannot print to a
PICTBRIDGE Printer

In the Setup menu, change the Computer Connection setting to
Other Application (

see page 36

).

Status

Solution
