N. specifications – Axion 8" TFT LCD TV with Card Reader User Manual
Page 26
N. Specifications
Display Specs:
Resolution
640 x 480
Viewing Angle
Hor: 60° deg., Vert: Top 50° deg.
Contrast Ratio
300:1
(Max)
Bottom 60° deg.
Brightness
300 Cd/
㎡
(Max)
Backlight Life
10,000 Hrs (Min)
Color System
NTSC
Screen type
LCD
Screen size
8 inches
Remote Control
Infrared rays
Antenna
Ext antenna
Channels
VHF Low : 2 ~ 6
VHF High : 7~13
UHF : 14 ~ 69
CATV : 1 ~ 125
Audio output
2 Watts
Power Input
DC 12 V, 2.5A
AC Power Source
Operating Humidity
10 ~ 75%
Operating Temperature 41°F to 104°F (5° to 40°C)
Storage temperature
4°F to 140°F (-15° to 60°C)
Dimensions (W x H x D)
(Excluding stand)
11
1/32
x 6
5 /8
x 1
9/16
Inches
(280 x 168 x 40 mm)
Weight
3.3 lbs (1.5 kg)
26
