Abocom WAP2101 - Manual

WAP2101
802.11b/g Portable Router
Description
The WAP2101 is a compact/Travel size IEEE802.11b/g Access Point with 1
Fast Ethernet port, which provides a powerful high-speed wireless
connection for compatible wireless-enabled devices into the network with
the freedom to roam. With web-based UI, this Access Point is easy to be
setup and maintained. All functions can be configured within the easy and
friendly user interface via web browser. Via the fast wireless network speed
of 54 Mbps, you can be very comfortable to have experience of high speed
web surfing, efiles downloading, online game playing, and video
conference session and streaming high quality multimedia materials. The
WAP2101 provides WAP/WAP2, 64/128 bit WEP encryption and
IEEE802.1x which ensures a high level of security to protect users' data
and privacy when you are traveling. Plus, the build-in power supply
inside the enclosure, there is no need to bring redundant power adapter for
your light travel need.
Specification
Standards IEEE 802.11 b/g standards compliant
Antenna High gain Internal Antenna (5dBi)
Frequency Range
802.11b/g
USA (FCC): 2.412GHz ~ 2.462GHz
Europe (ETSI): 2.412GHz ~ 2.472 GHz
Japan (TELEC): 2.412GHz ~ 2.483GHz
Number of Selectable
Channels
802.11b/g:
USA (FCC) 11 channels;
EU (ETSI) 13 channels;
Japan (TELEC) 14 channels
Data Rate
802.11b: 1, 2, 5,5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
Coverage Area
Indoor: up to 100M
Outdoor: up to 300M
Transmit Power (EIRP)
11b CCK: +17~19dBm
11g OFDM: +17~19dBm
Receiver Sensitivity
-68dBm at 54Mpbs, 10% PER ;
-82dBm at 11Mpbs, 8% PER ;
Power Requirement AC 110~240V
Certifications: FCC, CE
Features
Create temporary, personal, wireless access in your hotel
room or a coffee shop hotspot
Travel size design with build-in Power supply & Internal
high gain antenna.
High security with build-in Security: WEP 64/128, WPA,
WPA2, 802.1x and 802.11i
Support Router/AP, WDS (Bridge + Repeater), or Client
Mode
Advanced Quality of Service (QoS) - 802.11e, WMM
Applications
