Vollrath 219-02 - Manual (Page 9)

1
SECTION 1
INTRODUCTION
1.1 DESCRIPTION
The Model 219 Stoelting® Mix Pump, is a high capacity
pump that will pump 45 gallons of mix per hour. The pump
is easy to clean, assemble, and operate. The pump
features a built-in pressure relief valve to prevent excessive
pressure build up in the freezer cylinder and mix lines.
The same pump (with minor variations) is used for both
hopper or remote model freezers. The instructions in this
manual will apply to both the hopper and remote types.
1.2 SPECIFICATIONS
DIMENSIONS
Height 13” (33 cm)
Width 9” (22.86 cm)
Length 13-1/2” (34.29 cm)
WEIGHT
22 lbs. (9.98 kg)
ELECTRICAL(Remote)
115v, 60 Hz: @ .74 Amps
(220V, 50 Hz is available)
TUBING SIZE REQUIRED (Remote)
1/2” (1.27 cm) I.D.
3/4” (1.90 cm) I.D.
Figure 1. Model 219-02 Mix Pump
