User's Guide HDSP MADI

When Full LC Display Support is turned off, only a brief information about the first fader of the
block (channel and row) is sent. This brief information is also available on the LED display of
the Behringer BCF2000.

Tip for Mac OS X users: LC Xview (

www.opuslocus.com

) provides an on-screen display

emulating the hardware displays of a Logic/Mackie Control, for use with controllers that can
emulate a Logic/Mackie Control but do not have a display. Examples include the Behringer
BCF2000 and Edirol PCR series.

Deactivate MIDI in Background (menu Options) disables the MIDI control as soon as another
application is in the focus, or in case TotalMix has been minimized. This way the hardware con-
troller will control the main DAW application only, except when TotalMix is in the foreground.
Often the DAW application can be set to become inactive in background too, so that MIDI con-
trol is switched between TotalMix and the application automatically when switching between
both applications.

TotalMix also supports the 9th fader of the Mackie Control. This fader (labeled Master) will con-
trol the stereo output faders (lowest row) which are set up as Main Monitor outputs in the Moni-
tor panel. Always and only.

27.4 Mapping

TotalMix supports the following Mackie Control surface elements*:

Element:

Meaning in TotalMix:

Channel faders 1 – 8

volume

Master

fader

Main

Monitor

channel's

faders

SEL(1-8) + DYNAMICS

reset fader to Unity Gain

V-Pots

–

pan

pressing V-Pot knobs

pan = center

CHANNEL LEFT or REWIND

move one channel left

CHANNEL RIGHT or FAST FORWARD

move one channel right

BANK LEFT or ARROW LEFT

move eight channels left

BANK RIGHT or ARROW RIGHT

move eight channels right

ARROW UP or Assignable1/PAGE+

move one row up

ARROW DOWN or Assignable2/PAGE-

move one row down

Master Mute

PLUGINS/INSERT

Master

Solo

STOP

Dim Main Monitor

PLAY

Talkback

PAN

Mono

Main

Monitor

MUTE Ch. 1 – 8

Mute

SOLO Ch. 1 – 8

Solo

SELECT Ch. 1 – 8

Select

REC Ch. 1 – 8

in Submix mode only: select output bus

F1 - F8

load preset 1 - 8

select Main Monitor

F10 - F12

Monitor Phones 1 - 3

*Tested with Behringer BCF2000 Firmware v1.07 in Mackie Control emulation for Steinberg mode and with Mackie
Control under Mac OS X.
