Vollrath Cayenne Electric Griddles - Manual (Page 4)

O
peratOr
’
s
M
anual
4
ENGLISH
t
roUbleShooting
c
hart
T
120V ~ 1800Watt
N L1 G
3
1
2 2
Problem It might be caused by Course of Action
Pilot Light does not come on when
the temperature control is turned up.
The equipment is not plugged in. Plug equipment in.
Pilot Light malfunction. Replace Pilot Light.
The light comes on, equipment does
not heat.
Thermostat Control malfunction. Replace Thermostat Control.
Heating Element malfunction. Replace Heating Element.
S
ervice and
r
epair
There are no user serviceable parts within this appliance. To avoid serious injury or damage, never attempt to repair the equipment or replace a damaged power
cord yourself. Do not send equipment directly to the Vollrath Company. Please contact the qualified professional repair service listed below.
VOLLRATH Technical Service • 1-800-628-0832 • Email: [email protected]
When contacting the Authorized Professional Service Center, please be ready with the item number, model number (if applicable), serial number, and proof of
purchase showing the date the unit was purchased.
Callout Part Number Description
1 XTSA0007 Control Thermostat
2 XFTA0001 Heating Element, 120V ~ 1800 Watt
3 XAA0011 Pilot Light, 120V, Amber
T
220V ~ 3000Watt
L1 L2 G
3
1
2 2
Callout Part Number Description
1 XTSA0007 Control Thermostat
2 XFTA0005 Heating Element, 220V ~ 1500 Watt
3 XAA0002 Pilot Light, 220V, Red
electrical draWing - c
oUntertop
e
lectric
g
riddle
, m
odelS
~ 40715, 40716
