Vollrath Cayenne Cast Iron Plate Sandwich Presses, Panini Style - Manual (Page 6)

O
peratOr
’
s
M
anual
6
ENGLISH
Spare partS liSt - c
oUntertop
S
andWich
p
reSS
, m
odelS
~ 40794
and
40794-c
Callout Part Number Description
1 XAA0005 Power Cord, 120V, NEMA 5-15P Plug
1 1786001 Power Cord, 120V, NEMA 5-20P Plug (Canada only)
2 XAA0012 Power Cord Restraint
3 XTSI2004 Foot, Rubber
4 XTSI2030 Top Heating Element, 120V ~ 810 Watt
5 XTSI2006 Top Plate, Ribbed, Non-Coated
6 XTSI2007 Bottom Plate, Ribbed, Non-Coated
7 XTSA0007 Thermostat
8 N/A Bottom Cover
9 XTSI2005 Drip Tray
10 XAA0009 Control Panel Fascia
11 N/A Frame
12 XTSI2015 Control Knob (0-550)
13 XAA0011 Pilot Light, Red, 120 Volt
15 XTSI2035 Bottom Heating Element 120V ~ 990 Watt
16 XTSI2016 Handle, Steel
17 XTSI2017 Handle Grip, Plastic
18 XTSI2018 Handle Spring
19 XTSI2019 Hinge Axle, Front
20 XTSI2020 Hinge Axle Circlip
21 XTSI2021 Hinge Axle, Rear
22 XTSI2036 Wire Tube
23 XTSI2023 Brass Saddle Clamp
24 N/A Spring Cover
N/S XTSI2024 Hinge Axle Rear Cover
