DNS-3200 User’s Manual
6
The rear panel is as shown below:
Figure 1.2: DNS-3200 Rear panel
No
Description
1
Ultra320 SCSI external ports
2
Hot swap system fans
3
PS/2 mouse connector
4
RJ-45 Gigabit Ethernet port 1
5
RJ-45 Gigabit Ethernet port 2
6
Monitor output port
7
UPS port
8
PS/2 keyboard connector
9
Parallel port
10
Hot swap power module
1
2
3
5
6
7
8
9
10
4
