Pft8805 – Vogels PFT 8805 User Manual
Page 5
www.vogels.com
9532-010-Z00-00
X
Y
Z
Y+ 1/16"(1.3MM)
1/16"(1.3MM)
Y
Z = 60"(152CM)
Z = 55"(140CM)
Z = 50"(127CM) - 52"(132CM)
Z = 46"(117CM)
TV
15
16
5mm
2x
2x
11
10
Installation Guide
Installationsanleitung, Guía de Instalacíon, Guida de Installazione, Guide d’Installation, Installatie gids
PFT8805
From this point on it is recommended that minimum two
people to properly install the cross bar assemblies to the
frame rails.
