Hardware Setup
▍
MS-S0031
2-5
Hardware Setup
▍
MS-S0031
r
ear
p
aneL
i/o
eSATA Port
The eSATA (External SATA) port is for attaching the eSATA hard drive.
USB 2�0 Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as key-
board, mouse, or other USB-compatble devces. Supports data transfer rate up
to 480Mbt/s (H-Speed).
USB 3�0 Port
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data
transfer rate up to 5 Gbt/s (SuperSpeed).
Important
If you want to use a USB 3.0 device, you must use the USB 3.0 cable to con-
nect to the USB 3.0 port.
Please note that lag may occur when users connect the USB keyboard to
the USB 3.0 port and use it under DOS or BIOS Setup.
LAN Port
The standard RJ-45 LAN jack s for connecton to the Local Area Network (LAN).
You can connect a network cable to t.
Yellow Green/ Orange
LED Color LED State Condton
Left Yellow Off LAN lnk s not establshed.
On (steady) LAN lnk s establshed.
On (blnkng) The computer s communcatng wth another computer on the LAN.
Rght Green Off 10 Mbt/sec data rate s selected.
On 100 Mbt/sec data rate s selected.
Orange On 1000 Mbt/sec data rate s selected.
▶
▶
▶
•
•
▶
USB 2�0 Port
LAN Port
eSATA Port USB 3�0 Port
LAN Port
