DISTRIBUTION AMPLIFIERS
6
OPERATION 7
The DA1226AT will operate successfully as long as
cables are attached correctly and other technical
specifications are followed. There are no other
adjustments necessary to operate the unit.
ACCESSORIES 8
Model No. Description
RACK MOUNT HARDWARE
DA1292FC 19”-1U Rack Mount Ears for rack
wide units
DA1293FC HIGH RESOLUTION 5-CHANNEL
COAX CABLE (for input of output)
CB4203MR 3 feet, 5-BNC M to 5-BNC M
CB4206MR 6 feet, 5-BNC M to 5-BNC M
CB4212MR 12 feet, 5-BNC M to 5-BNC M
CB4225MR 25 feet, 5-BNC M to 5-BNC M
CB4250MR 50 feet, 5-BNC M to 5-BNC M
CHB4275MR 75 feet, 5-BNC M to 5-BNC M
CB42100MR 100 feet, 5-BNC M to 5-BNC M
CB42150MR 150 feet, 5-BNC M to 5-BNC M
DA1226AT SUPER HIGH RESOLUTION 5-
CHANNEL COAX CABLE (for input
or output)
CB4406MR 6 feet, 5-BNC M to 5-BNC M
CB4412MR 12 feet, 5-BNC M to 5-BNC M
CB4425MR 25 feet, 5-BNC M to 5-BNC M
CB4450MR 50 feet, 5-BNC M to 5-BNC M
CB4475MR 75 feet, 5-BNC M to 5-BNC M
CB44100MR 100 feet, 5-BNC M to 5-BNC M
CB44150MR 150 feet, 5-BNC M to 5-BNC M
HIGH RESOLUTION PLENUM-
FLEX 5-CHANNEL COAX CABLE
CB500PL-
5BM00035BM 3 feet, 5BNC M to 5-BNC M
CB500PL-
5BM00065BM 6 feet, 5BNC M to 5-BNC M
CB500PL-
5BM00125BM 12 feet, 5BNC M to 5-BNC M
CB500PL-
5BM00255BM 25 feet, 5BNC M to 5-BNC M
CB500PL-
5BM00505BM 50 feet, 5BNC M to 5-BNC M
CB500PL-
5BM00755BM 75 feet, 5BNC M to 5-BNC M
CB500PL- 100 feet, 5BNC M to 5-BNC M
5BM01005BM
CB500PL-
5BM01505BM
150 feet, 5BNC M to 5-BNC M
CB500PL-
5BM02005BM 200 feet, 5BNC M to 5-BNC M
CB500PL-
5BM02505BM 250 feet, 5BNC M to 5-BNC M
SUPER HIGH RESOLUTION
PLENUM-FLEX 5-CHANNEL
COAX CABLE
CB5100PL –
5BM00035BM 3 feet, 5-BNC M to 5-BNC M
CB5100PL-
5BM00065BM 6 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM00125BM 12 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM00255BM 25 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM00505BM 50 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM00755BM 75 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM01005BM 100 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM01505BM 150 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM02005BM 200 feet, 5-BNC M to 5-BNC M
CB5100PL –
5BM02505BM 250 feet, 5-BNC M to 5-BNC M
VGA TO RGB ADAPTER CABLES
MS8102CA 15-pin HD M to 5 BNC M, 6ft
MS8104CA 15-pin HD M to 5 BNC M, 15ft
MS8105CA 15-pin HD M to 5 BNC M, 50ft
MS8112CA 15-pin HD F to 5 BNC M, 6ft
MS8114CA 15-pin HD F to 5 BNC M, 15ft
POWER CABLES
PC5301US Power Cable for US
PC5302UK Power Cable for UK
PC5303AU Power Cable for Australia
PC5304GR Power Cable for Germany
