DISTRIBUTION AMPLIFIERS
3
cause harmful interference in which case the
user will be required to correct the
interference at his own expense.
•
Any changes or modifications to this unit not
expressly approved by Altinex Inc. could void
the user’s authority to operate the
equipment.
ABOUT YOUR DISTRIBUTION AMPLIFIER 2
The DA1226AT is a 1-in 6-out RGBHV distribution
amplifier designed to allow the connection of a
single computer video or interface source to as
many as six monitors or projectors capable of
handling the source resolution.
The DA1226AT offers excellent bandwidth
performance (minimum 350 MHz) and a typical
bandwidth of nearly 450 MHz, allowing it to remain
virtually transparent to high resolution signals.
Though primarily designed to pass an RGBHV
signal format, the DA1226AT can also pass RGBS,
RGsB, Component Video (Y, R-Y, B-Y), S-Video
(Y/C), and Composite Video by using the
appropriate channels. The DA1226AT outputs the
same sync level as it receives on its input.
The DA1226AT offers a low-profile design, which
helps to prevent tilting due to cable drag when
used in desktop applications. The DA1226AT uses
an internal 90-140/200-240V switchable power
supply. It may be rack-mounted using optional
hardware.
TECHNICAL SPECIFICATIONS 3
FEATURES/DESCRIPTION DA1226AT
GENERAL
No. of Inputs
One
Input Connectors Set of 5 BNC Female
No. of Outputs Six
Output Connectors Set of 5 BNC Female
Compatibility High resolution
RGBHV, RGBS, RGsB
and RsGsBs,
Component, S-Video
and Composite Video
Table 1. DA1226AT General
MECHANICAL DA1226AT
Material 0.1” Al
Finish Gray
Front/Back panels Lexan
Height (inches) 1.75in (44mm) (1U)
Width (inches) 17.0in (432mm) (1 rack
wide)
Depth (inches) 4.50in (114mm)
Weight (pounds) 5.0lbs (2.27kg)
Ship Weight (pounds) 7.0lbs (3.18kg)
T
°
Operating 10
°
C-35
°
C
T
°
Maximum 50
°
C
Humidity 90
%
non-condensing
MTBF (calculations) 40,000 hrs
Table 2. DA1226AT Mechanical
ELECTRICAL DA1226AT
Input Video Signal
Analog Signal
1.5V p-p max
Impedance 75 Ohms
Input Sync Signal
Horizontal, Vertical, & C-
Sync
TTL(+/-)
Sync on Green -0.3V
Impedance 10 k Ohms
Output Video Signals
Analog Signal
Gain of 1.05 (+/-5%)
Fall/Rise Time (ns) 1.0
Impedance 75 Ohms
Output Sync Signal
Composite Sync, (Horizontal,
Vertical)
TTL(+/-)
Sync on Green -0.3V
Impedance 22 Ohms
Frequency Compatibility
Horizontal
15-200 kHz
Vertical 47-180 Hz
Typical Video Bandwidth 450 MHz @ -3dB
Minimum Video Bandwidth 350 MHz @ -3dB
Cable Equalization 3dB @ 120 MHz
Coupling DC
Cross-talk -40dB @10 MHz
Power
Internal Power Supply
90-140/200-240 V
switchable
Power Consumption 10 watts max
Table 3. DA1226AT Electrical
