BIOS Setup

▍

MS-7623

3-23

BIOS Setup

▍

MS-7623

Advance DRAM Configuraton

Press to enter the sub-menu and the followng screen appears.

DRAM Tmng Mode

Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect)

EEPROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the

followng “Advance DRAM Configuraton” sub-menu to be determned by BIOS based

on the configuratons on the SPD. Selectng [Manual] allows users to configure the

DRAM tmngs and the followng related “Advance DRAM Configuraton” sub-menu

manually.

FSB/DRAM Rato

Ths tem allows you to select the rato of FSB/ DRAM.

Adjusted DRAM Frequency (MHz)

It shows the adjusted Memory frequency. Read-only.

HT Lnk Control

Press to enter the sub-menu.

HT Incomng/ Outgong Lnk Wdth

These tems allow you to set the Hyper-Transport Lnk wdth. Settng to [Auto], the

system wll detect the HT lnk wdth automatcally.

HT Lnk Speed

Ths tem allows you to set the Hyper-Transport Lnk speed. Settng to [Auto], the sys-

tem wll detect the HT lnk speed automatcally.

Adjusted HT Lnk Frequency (MHz)

It shows the adjusted HT Lnk frequency. Read-only.

Adjust PCI-E Frequency (MHz)

Ths field allows you to select the PCIE frequency (n MHz).

Auto Dsable DRAM/PCI Frequency

When set to [Enabled], the system wll remove (turn off) clocks from empty DRAM/ PCI

slots to mnmze the electromagnetc nterference (EMI).

▶
