Hardware Setup MS-7599
Chapter 2
2-9
Hardware Setup MS-7599
Chapter 2
Back Panel
Optcal S/PDIF-Out
Ths S/PDIF (Sony & Phlps Dgtal Interconnect Format) connector s provded for dg-
tal audo transmsson to external speakers through an optcal fiber cable.
Mouse/Keyboard
The standard PS/2 ® mouse/keyboard DIN connector s for a PS/2 ® mouse/keyboard.
Seral Port
The seral port s a 16550A hgh speed communcatons port that sends/ receves 16
bytes FIFOs. You can attach a seral mouse or other seral devces drectly to the con-
nector.
USB 2.0 Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces. Supports data transfer rate up to 480Mbt/s
(H-Speed).
LAN
The standard RJ-45 LAN jack s for connecton to
the Local Area Network (LAN). You can connect a
network cable to t.
LED Color LED State Condton
Left Yellow Off LAN lnk s not establshed.
On(Steady state) LAN lnk s establshed.
On(brghter & pulsng) The computer s communcatng wth another computer on the LAN.
Rght Green Off 10 Mbt/sec data rate s selected.
On 100 Mbt/sec data rate s selected.
Orange On 1000 Mbt/sec data rate s selected.
▶
▶
▶
▶
▶
Seral Port
LAN
Lne-In
Lne-Out
Mc
RS-Out
CS-Out
SS-Out
USB 2.0 Port USB 2.0 Port
USB 2.0 Port
Optcal S/PDIF-Out
Mouse/Keyboard
Yellow Green/ Orange
USB 2.0 Port
