Hardware Setup MS-7680
Chapter 2
2-11
Hardware Setup MS-7680
Chapter 2
Back Panel
Mouse/Keyboard
The standard PS/2 ® mouse/keyboard DIN connector s for a PS/2 ® mouse/keyboard.
USB 2.0 Port
The USB (Unversal Seral Bus) port s for attachng USB devces such as keyboard,
mouse, or other USB-compatble devces.
USB 3.0 Port (optonal)
USB 3.0 port s backward-compatble wth USB 2.0 devces. Supports data transfer rate
up to 5 Gbt/s (SuperSpeed).
Important
If you want to use a USB 3.0 devce, you must use the USB 3.0 cable to connect to the
USB 3.0 port.
HDMI Port (optonal)
The Hgh-Definton Multmeda Interface (HDMI) s an all-dgtal audo/vdeo nterface
capable of transmttng uncompressed streams. HDMI supports all TV format, nclud-
ng standard, enhanced, or hgh-definton vdeo, plus mult-channel dgtal audo on a
sngle cable.
VGA Port
The DB15-pn female connector s provded for montor.
DVI-D Port
The DVI-D (Dgtal Vsual Interface - Dgtal) connector allows you to connect a LCD
montor. It provdes a hgh-speed dgtal nterconnecton between the computer and ts
dsplay devce. To connect an LCD montor, smply plug your montor cable nto the DVI
-D connector, and make sure that the other end of the cable s properly connected to
your montor (refer to your montor manual for more nformaton.)
Important
The HDMI, VGA and DVI-D dsplay nterfaces on the manboard are desgned to serve
as IGP (Integrated Graphcs Processor) used. If you nstalled a processor wthout
ntegrated graphcs chp, these dsplay ports wll have no effect.
▶
▶
▶
▶
▶
▶
HDMI Port
Lne-In
Lne-Out
Mc
VGA Port
USB 3.0 Port
DVI-D Port
RS-Out
CS-Out
SS-Out
Mouse/ Keyboard
USB 2.0 Port USB 2.0 Port
(optonal)
LAN
(optonal)
(optonal)
