Gettng Started
Manboard Specficatons
Processor Support
Intel ® Sandy Brdge processor n the LGA1155 package
(For the latest nformaton about CPU, please vst
http://www.ms.com/servce/cpu-support)
Chpset
Intel ® H61 chpset
Memory Support
2 DDR3 DIMMs support DDR3 1333/ 1066 DRAM (16GB Max)
Supports Dual-Channel mode
(For more nformaton on compatble components, please vst
http://www.ms.com/servce/test-report)
LAN
Supports LAN 10/100/1000 by Realtek ® RTL8111E
Audo
HD audo codec ntegrated by Realtek ® ALC887
Flexble 8-channel audo wth jack sensng
SATA
4 SATA 3Gb/s ports by Intel ® H61 PCH (H61MU-E35/ H61M-E33/ H61M-E23)
2 SATA 3Gb/s ports by Intel ® H61 PCH (H61M-P33)
USB 3.0 (for H61MU-E35)
2 USB 3.0 rear IO ports by NEC ® uPD720200F1
Connectors
Back panel
1 PS/2 keyboard/ mouse combo port
2 USB 3.0 ports (for H61MU-E35)
4 USB 2.0 ports
1 HDMI port* (H61MU-E35/ H61M-E33/ H61M-E23)
1 VGA port*
1 DVI-D port*
1 LAN port
6 flexble audo ports (H61MU-E35/ H61M-E33) / 3 flexble audo ports (H61M-E23/
H61M-P33)
*(The HDMI, DVI-D and VGA ports only work wth Integrated Graphcs Processor)
■
■
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-
