2-24

Hardware Setup

MS-7681

Chapter 2

LED Status Indcators

APS LED (P67A-GD65/ P67A-GD55/ P67A-GD53/ P67S-GD53)

The APS (Actve Phase Swtchng) LED ndcate the current CPU power phase mode.

Follow the nstructons below to read.

: Lghts : Off

CPU s n 1 phase power mode.
CPU s n 2 phase power mode.
CPU s n 3 phase power mode.
CPU s n 4 phase power mode.
CPU s n 5 phase power mode.
CPU s n 6 phase power mode.

Dual BIOS LED (P67A-GD65)

The Dual BIOS LED ndcates the BIOS status durng system power on. Follow the

nstructons below to read.

Off: Normal.

Blnk (1 cycle/second): The prmary BIOS s faled.

Fast Blnk (10 cycles/second): The second BIOS s faled.

Sold: Both of prmary and second BIOS are faled.

APS LEDs

(optonsl)

Dual BIOS LED

(optonsl)
