Page 27
MS-7314 Mainboard
2-14
Serial Port Connector: JCOM1
This connector is a 16550A high speed communication port that sends/receives 16
bytes FIFOs. You can attach a serial device.
PIN
SIGNAL
DESCRIPTION
1
DCD
Data Carry Detect
2
SIN
Serial In or Receive Data
3
SOUT
Serial Out or Transmit Data
4
DTR
Data Terminal Ready
5
GND
Ground
6
DSR
Data Set Ready
7
RTS
Request To Send
8
CTS
Clear To Send
9
RI
Ring Indicate
Pin Definition
JCOM1
Front Panel Audio Connector: JAUD1
This connector allows you to connect the front panel audio and is compliant with
Intel
®
Front Panel I/O Connectivity Design Guide.
Pin Definition
PIN
SIGNAL
DESCRIPTION
1
MIC_L
Microphone - Left channel
2
GND
Ground
3
MIC_R
Microphone - Right channel
4
NC
5
LINE out_R
Analog Port - Right channel
6
MIC_JD
Jack detection return from front panel microphone JACK1
7
Front_JD
Jack detection sense line from the High Definition Audio CODEC
jack detection resistor network
8
NC
No control
9
LINE out_L
Analog Port - Left channel
10
LINEout_JD
Jack detection return from front panel JACK2
JAUD1
1
2
9
10
1
9
2
