MS-7314 Mainboard
2-4
Important
- DDR2 memory modules are not interchangeable with DDR and the DDR2
standard is not backwards compatible. You should al ways instal l DDR2
memory modules in the DDR2 DIMM slots.
- To enable successful system boot-up, always insert the memory modules
into the DIMM1 first.
- Due to the chipset specification, the mainboard will only supports to install one
double-side (2GB max) memory module, or to install two single-side memory
modules (1GB max per DIMM).
Compatible DDR2 533 memory list
Please refer to the following list to find the available DDR2 memory modules.
Vendor Model Size
HYNIX HYMP532U646-C4 (HYNIX HY5PS121621 F-C4) 256MB
Kingston KVR533D2N4/256 (ELPIDA) 256MB
SEC M378T3253FG0-CD5DS (SEC K4T56083F-GCD5) 256MB
SEC M378T3253FG0-CD5 (SEC K4T56083QF-GCD5) 256MB
Aeneon AET660UD00-370A98X 512MB
AENEON AET660UD00-370B97X (AENEON AET93R370B) 512MB
Elixir M2U51264TU88A2B-37B (Elixir N2TU51280AE-37B) 512MB
Hynix HYMP564U64P8-C4 (Hynix HY5PS12821FP-C4) 512MB
Kingmax KLBC28F-A8KB4 [EGES] (Kingmax KKEA88B4IAUG-37DA) 512MB
Micron MT4HTF6464AY-53EE1 (Micron D9HNV) 512MB
UMAX 53014051-7100 (UMAX U2S12D30TP-5C) 512MB
Aeneon AET760UD00-370A98X (Aeneon AET93F370A) 1GB
AENEON AET760UD00-370B97X (AENEON AET93R370B) 1GB
KINGSTON KVR533D2N4/1G (Hynix HY5PS12821CFP-Y5) 1GB
Micron MT8HTF12864AY-53EA1 (Micron D9DMT) 1GB
Micron MT8HTF12864AY-53EE1 (Micron D9HNH) 1GB
TakeMS TMS1GB264C081-534AP (TakeMS MS18T51280-3.7) 1GB
UMAX 53016033-7100 (UMAX U2S12D30TP-5C) 1GB
KINGSTON KVR533D2N4/2G (ELPIDA E1108AB-6E-E) 2GB
