En-4
MS-7522 Manboard
▍
RESET Clr
CMOS
Q
uick
c
oMponentS
G
uide
Back Panel,
En-11
CPU, En-5 DDR3, En-9
JPWR1, En-13
IDE1, En-16
JCI1,En-18
JUSB1~3, En-19
JCOM1, En-20
JPWR2, En-13 CPUFAN1, En-17
J1394_1, En-18
CPU_CLK1, En-22
CLR_CMOS1, En-23
RESET1, En-23
POWER1, En-23
JCD1, En-18
JAUD1, En-19
JFP1, JFP2, En-17
PCIE Slot, En-24
PCI Slot, En-26
SYSFAN2, En-17
SYSFAN1,3, En-17
SATA1~7, En-16
JSP1, En-21
JTPM1, En-20
