2-16
BIOS Setup
CPU Core Voltage/ DRAM Voltage/ GPU Voltage/ System Agent Voltage (SA)/ CPU
PLL Voltage/ DDR_VREF_CA_A/ DDR_VREF_CA_B/ DDR_VREF_DA_A/ DDR_VREF_
DA_B/ PCH 1.05
These tems are used to adjust the voltage of CPU, Memory, GPU and chpset.
Current CPU Core Voltage/ Current DRAM Voltage/ Current GPU Voltage
These tems show current CPU/ DRAM/ GPU voltage. Read-only.
Overclockng Profiles
Press to enter the sub-menu.
Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Press to enter the sub-menu.
Set Name for Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Gve a name by typng n ths tem.
Save Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Save the current overclockng settngs to ROM for selected profile.
Load/ Clear Overclockng Profile 1/ 2/ 3/ 4/ 5/ 6
Load/ Clear the stored profile settngs from ROM.
OC Profile Save to USB
Save the current overclockng settngs to USB flash dsk.
OC Profile Load from USB
Load the stored settngs from USB flash dsk.
CPU Specficatons
Press to enter the sub-menu. Ths sub-menu hghlghts all the key features of
your CPU. The nformaton wll vary by model and s read-only. You can also access ths
nformaton at any tme by pressng [F4]. Press to enter the sub-menu.
CPU Technology Support
Press to enter the sub-menu. The sub-menu shows the nstalled CPU tech-
nologes. Read only.
MEMORY-Z
Press to enter the sub-menu. Ths sub-menu hghlghts all the settngs and
tmngs of your DIMMs. Ths nformaton wll vary by model and s read-only. You can
also access ths nformaton at any tme by pressng [F5]. Press to enter the
sub-menu.
DIMM1~4 Memory SPD
Press to enter the sub-menu. The sub-menu dsplays the nformatons of
nstalled memory.
CPU Features
Press to enter the sub-menu.
Actve Processor Cores
Ths tem allows you to select the number of actve processor cores.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
