Chapter 1
1-5 Getting Started
USB A88X-G41 PC Mate/ A78-G41 PC Mate
AMD A88X/ A78 Chipset
4x USB 3.0 ports (2 ports on the back panel, 2 ports available
through the internal USB connectors)
10x USB 2.0 ports (4 ports on the back panel, 6 ports available
through the internal USB connectors)
A58-G41 PC Mate/ A55-G41 PC Mate
AMD A58/ A55 Chipset
12x USB 2.0 ports (6 ports on the back panel, 6 ports available
through the internal USB connectors)
■
-
-
-
■
-
-
Audio Realtek ® ALC887 Codec ■
LAN Realtek ® RTL8111E Gigabit LAN controller ■
Back Panel
Connectors
1x PS/2 keyboard port
1x PS/2 mouse port
4x USB 2.0 ports, 2x USB 3.0 ports (A88X-G41 PC Mate/ A78-G41
PC Mate)
6x USB 2.0 ports (A58-G41 PC Mate/ A55-G41 PC Mate)
1x VGA port
1x DVI-D port
1x HDMI port
1x LAN (RJ45) port
3x audio jacks
■
■
■
■
■
■
■
■
■
Internal
Connectors
1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
6x SATA 6Gb/s connectors (A88X-G41 PC Mate/ A78-G41 PC
Mate)
6x SATA 3Gb/s connectors (A58-G41 PC Mate/ A55-G41 PC Mate)
3x USB 2.0 connectors (supports additional 6 USB 2.0 ports)
1x USB 3.0 connector (supports additional 2 USB 3.0 ports) (A88X-
G41 PC Mate/ A78-G41 PC Mate)
1x 4-pin CPU fan connector
2x 4-pin system fan connectors
1x 3-pin system fan connector
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Serial port connector
1x Parallel port connector
1x Clear CMOS jumper
2x USB power jumpers
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
I/O
Controller
Fintek 71878 Controller Chip ■
