Chapter 1 – MSI Z77A-G41 User Manual
Page 15

1-5
MS-7758
Chapter 1
Connectors
Back panel
1x PS/2 mouse port
1x PS/2 keyboard port
4x USB 2.0 ports
2x USB 3.0 ports
1x LAN port
1x HDMI port**, supports a maxmum resoluton of 1920x1200 @ 60 Hz
1x VGA port**, supports a maxmum resoluton of 2048x1536 @ 75 Hz
3x audo ports***
(**Ths manboard supports dual-dsplay functon by two onboard graphcs output
ports).
(***To reach the 8-channel sound effect, the 7th and 8th channels must be outputted
from front panel.)
On-Board
2x USB 2.0 connectors
1x USB 3.0 connector
1x TPM Module connector
1x Seral Port connector
1x Parallel Port connector
1x Front Panel Audo connector
1x Chasss Intruson connector
1x MultConnect Panel connector (optnoal)
1x Voce Gene connector (optonal)
Slots
1x PCIe 3.0 x16 slot, PCI_E2, t supports up to PCIe 3.0 x16 speed
1x PCIe 2.0 x16 slot, PCI_E4, t supports up to PCIe 2.0 x4 speed
2x PCIe 2.0 x1 slots
2x PCI slots
Form Factor
ATX (30.5 cm X 21.6 cm)
Mountng Screw Holes
6x mountng holes
For the latest nformaton about CPU, please vst
http://www.ms.com/servce/cpu-support
For more nformaton on compatble components, please vst
http://www.ms.com/servce/test-report
■
-
-
-
-
-
-
-
-
■
-
-
-
-
-
-
-
-
-
■
■
■
■
■
■
